5
EtherNet/IP
5.1 Introduction
The Inspector PIM60 can be controlled and results
retrieved using the EtherNet/IP standard, see
http://www.odva.org/.
To be able to use EtherNet/IP, the EtherNet/IP option has to be enabled and the connection
and output result setup has to be made, see the Operating Instructions for Inspector PIM60.
5.2 Get results via EtherNet/IP
The following settings are configured in the Ethernet Result Output dialog in the InspectorPIM60
menu.
5.2.1 Attributes
Attributes are used to control the formatting and identification of inspection results. Some
of them can be controlled directly in the Ethernet Result Output dialog in the section Message
settings. All available attributes are listed in the table in section XML Formatting in Sec-
tion A.3.2, Attributes (page 49).
Degrees/Radians Choose unit for the rotation for object locator, angle for blobs,
angle for edges, and angle measurements.
Pixels/Millimeters Choose if position coordinates and distance measurements
should be sent in pixel or millimeter unit.
Note: The device must be calibrated for it to be possible to use
the “mm” attribute. An error message is given in the output string
if the device is not calibrated and mm is chosen.
5.2.2 Example formatting strings
The auto-generated example string will vary depending on the configuration in the selected
reference object. The intention with the example string is to give an idea of the available tags
and to be a good starting point for creating a suitable format.
Below follow some short descriptions of example strings for different configurations. For more
information about the XML formatting see Appendix A, Result output formatting (page 39).
Example string for configuration with only an Object locator
<IMAGE_NUMBER dataType="DINT" pos="0"/>
<OBJECT_LOC>
<DECISION dataType="SINT" pos="0"/>
<SCORE dataType="REAL" pos="0"/>
<SCALE dataType="REAL" pos="1"/>
<X dataType="REAL" pos="2"/>
<Y dataType="REAL" pos="3"/>
<ROTATION dataType="REAL" pos="4"/>
</OBJECT_LOC>
Analyzed image’s number
Start of container for object locator
Decisions reports whether the object was found (=1) or not found (=0)
