SICK OD1000 User Manual

1
6
8
2
9
ß
à
á
ã
â
7
ä
SICK AG
D-79183 Waldkirch
Made in Germany
OD1000
OD1000-6001R15
1 075 638
SN16100001
MAR 2016
EN/IEC 60825-1:2014
Complies with 21 CFR
1040.10 and 1040.11
except for deviations
pursuant to laser
notice No. 50, dated
June 24, 2007
CLASS 1 LASER PRODUCT
DC 18 - 30 Vdc class 2
Qout: < 100 mA
Q
A
out: 4 - 20 mA/0 - 10 V
Amb. Temp.: < 50 °C
Power Con.: < 2.5 W
Enclosure Type: 1
brown
blue
black
white
gray
1
3
4
2
5
LASER APERTURE
L+
M
Q1/C
Q2/Q
A
In1
LASER
1
5
25
3
4
Figure 3: OD1000 type label
1
EFUP information for China
2
Protection class
3
RCM conformity mark
4
EU conformity mark
5
2D code with part number and serial number
6
Laser information
7
Laser radiation direction
8
IO-Link symbol
9
Pin assignment
ß
Electrical data and environmental data
à
Month and year of manufacture
á
Serial number
â
Part number
ã
Type code
ä
Device family
Device display
The following information can be called up using the info menu on the device display:
•
Firmware verification
•
Serial number
•
Sensor operating hours
•
Laser operating hours
•
Sensor status (error history)
•
Part number
PRODUCT DESCRIPTION 3
8019642/ZJW1/2017-04-03 | SICK O P E R A T I N G I N S T R U C T I O N S | OD1000
13
Subject to change without notice
