Display Status Meaning
Output displays Q
1
Ö Ö Simultaneous
Teach-in operation is carried out
Ö Ö 5 seconds in alter‐
nation
Teach-in operation has failed
Ö Ö Permanently in
alternation
There is a fault
o
Does not light up
Ö
Flashing
O
Permanently on
7.2.2 Operating buttons
Pushbutton Function Description
Open menu/
confirm
Opens the menu, confirms entries, or switches to the next menu
level of a selected element.
Moves the cursor to the right when entering numbers.
Cancel Switches to the previous menu level.
Moves the cursor to the left when entering numbers.
Navigate Switches between multiple screens on one menu level.
Increases the value when entering numbers.
Navigate Switches between multiple screens on one menu level.
Reduces the value when entering numbers.
Activating / Deactivating the operating button lock
The operating buttons can be locked / unlocked using a shortcut in order to prevent
accidental operation:
b
Press and hold the and pushbuttons simultaneously for > 3 seconds.
✓
When the pushbutton lock is activated, the padlock symbol appears in the dis‐
play. When the pushbutton lock is deactivated, the padlock symbol is not dis‐
played.
NOTE
The operating button lock can also be activated / deactivated via SOPAS ET or IO-Link.
7.3 Operating concept
The device can be operated using the following methods:
•
Display and operating buttons on the device, see "Operation via display",
page 22.
•
SOPAS ET user interface (PC), see "Operation via SOPAS ET", page 56.
•
IO-Link, see "Operation via IO-Link", page 55.
OPERATION 7
8019642/ZJW1/2017-04-03 | SICK O P E R A T I N G I N S T R U C T I O N S | OD1000
21
Subject to change without notice
