13 Technical data
NOTE
The relevant online data sheet for your product can be downloaded, saved, and printed,
including technical data, dimensions, and connection diagrams:
b
www.sick.com/OD1000
13.1 Performance
Table 10: Technical data for performance
Measuring range 200 mm ... 1,000 mm
1
Resolution 50 µm
2
Reproducibility 0.4 mm
2
,
3
Linearity ± 1.5 mm
2
,
4
Response time 1.5 ms
5
Measuring frequency ≤ 3 kHz
Light sender Laser, red (visible, wavelength 655 nm, max. pulse output
0.78 mW, max. average power 0.39 mW, max. pulse duration
1.8 ms)
Laser class 1 (EN 60825-1:2014)
Typical light spot size 1.5 mm x 1.5 mm
Additional function Adjustable averaging or median filter, switching mode: distance to
object (DtO), window or ObSB (object between sensor (device) and
background), teachable switching output, invertible switching out‐
put, teachable analog output, invertible analog output, switchable
analog output mA/V, multifunctional input: laser off / external
teach-in / deactivated, display switch-off, user interface lock, dis‐
play can be rotated by 180°, alarm function, edge height change,
time functions (ON/OFF delay), 1-shot)
1
6% ... 90% remission, with standard settings
2
90% remission (white), with constant ambient conditions
3
Statistical error 3 σ
4
For optimum performance observe min. warm-up time of 10 minutes
5
With measuring frequency of 3 kHz, target change white 90%/white 90%
13 TECHNICAL DATA
62
O P E R A T I N G I N S T R U C T I O N S | OD1000 8019642/ZJW1/2017-04-03 | SICK
Subject to change without notice
