Connection type 20 cm cable with M12 male connector, 5-pin
Display OLED display, 3 status LEDs
Weight 280 g
Dimensions see "Setup and dimensions", page 12
Enclosure rating IP 65, IP 67
Protection class III in accordance with EN 50178
1
Limit values, reverse-polarity protected. Operation in short-circuit protected network: max. 8 A.
2
May not fall short of or exceed U
v
tolerances
3
Without load, at +20 °C
13.4 Ambient data
Table 13: Ambient data
Ambient operating temperature –10 °C … +50 °C
1
Storage temperature –20 °C … +60 °C
Temperature drift 0.15 mm/K
Typ. ambient light immunity Artificial light: ≤ 3,000 lx
2
Sunlight: ≤ 10,000 lx
Vibration resistance EN 60068-2-6 / EN 60068-2-64
Shock resistance EN 60068-2-27
1
At UV = 24 V
2
With constant object movement in the measuring range
13 TECHNICAL DATA
64
O P E R A T I N G I N S T R U C T I O N S | OD1000 8019642/ZJW1/2017-04-03 | SICK
Subject to change without notice
