PROGRAMMING TOOL | SICK8016223/19SR/2020-11-02
Subject to change without notice
19
PGTPGT-08-S@SOPA S
Parameter
AFS60B-xxPxxxxxxx
AFS60A-xxPxxxxxxx
AFM60B-xxRxxxxxxx
AFM60A-xxRxxxxxxx
AFM60B-xxSxxxxxxx
AFM60A-xxSxxxxxxx
AFM60B-xxPxxxxxxx
AFM60A-xxPxxxxxxx
AHS36A-xxPxxxxxxx
AHM36A-xxPxxxxxxx
Description
Position Error
Bit
xed
directly
added
xed
directly
added
Denesthepositionoftheer-
rorbit.Choosebetweenxed
or directly added (the error
bit is transmitted immediately
after the last position bit).
Preset Position X X X X X Assigns the entered preset
position to the current shaft
position.
SSI Mode synchronous
asynchro-
nous
synchronous
asynchro-
nous
Deneswhetherpositionsare
formed regardless of the mas-
ter clock (asynchronous) or
synchronously to the master
clock.
Electrical inter-
face TTL/HTL
X Denestheoutputinterface
for the incremental signals.
Reset to factory
settings
X X X X X Resets all parameters to
the factory settings of the
encoder.
b After programming, print ( ) a label with the programmed data and
stick it onto the encoder.
This means that the settings with which the encoder is being used are visible from
the outside.
Standard labels are suitable for printing.
Note:
Data entered is written to the encoder immediately and directly as long as this has not
beenalteredintheSOPASconguration(seeonlinehelp).
