SICK PGT-08-S User Manual

PROGRAMMING TOOL | SICK8016223/19SR/2020-11-02
Subject to change without notice
27
PGTPGT-08-S@SOPA S
5.4 Connection diagrams
Encoder type Connection type
DFS60/DFS2x/DFV60/VFS60 DSL-2D08-G0M5AC3 (M12, 8-pin)
DSL-3D08-G0M5AC3 (M23, 12-pin)
A
A
DATA
A
DATA
B
SET
B
V/R
US
CLK
Z
CLK
Z
GND
1
2
3
4
5
6
7
8
1. White 5. Red
2. Brown 6. Violet
3. Pink 7. Yellow
4. Black 8. Blue
