PROGRAMMING TOOL | SICK8016223/19SR/2020-11-02
Subject to change without notice
23
PGTPGT-08-S@SOPA S
4.8 Loading/saving encoder data (*.sopas)
4.8.1 Loading encoder data
To import encoder data saved in SOPAS as device data, proceed as follows:
1. Click on
DEVICE.
2. Select
IMPORT...
3. Selectthedesireddevicele.
4. Click on
OPEN.
Theledataistransferredtotheconnectedencoder.
4.8.2 Saving encoder data
To program multiple encoders with the same values or to switch between multiple sets
ofprogrammingquickly,SOPASallowsyoutosaveadeviceconguration.
1. Click on
DEVICE.
2. Select
EXPORT...
3. Inthedialogboxthatfollows,selectthedesiredleformat.
4. Click on the
BROWSE button.
5. Enteralename.
Tip:
Useameaningfullenameinordertoquicklyndaspeciccongurationlater,e.g.,
DFS60-A_1000L_EL_180CHANB_HTL.
6. Click on
SAVE.
7. Click on
EXPORT.
