PROGRAMMING TOOL | SICK 8016223/19SR/2020-11-02
Subject to change without notice
14
PGT PGT-08-S@SOPA S
4.3 Setting up the encoder
1. Create a new project (see page 11).
2. Connect the PGT-08-S hardware with the connected encoder to the PC.
3. Click the
button.
CAUTION
Risk of damage due to incorrect adapter cable!
The programming tool must only be used with the designated adapter cables (see
page 26). Other adapter cables are not permitted. Otherwise, this could result in
damage to the programming tool and/or the encoder.
4. Oncetheencoderisfound,conrmthatthecorrectcableisconnected.
