SICK PGT-08-S User Manual

PROGRAMMING TOOL | SICK 8016223/19SR/2020-11-02
Subject to change without notice
28
PGT PGT-08-S@SOPA S
Encoder type Connection type
AFS60/AFM60 SSI DSL-2D08-G0M5AC2 (M12, 8-pin)
DSL-3D08-G0M5AC2 (M23, 12-pin)
A
A
DATA
A
DATA
B
SET
B
V/R
US
CLK
Z
CLK
Z
GND
1
2
3
4
5
6
7
8
1. White 5. Red
2. Brown 6. Yellow
3. Pink 7. Violet
4. Black 8. Blue

SICK PGT-08-S Specifications

General

Brand	SICK
Model	PGT-08-S
Category	Media Converter
Language	English
