Page #21 background image
PROGRAMMING TOOL | SICK8016223/19SR/2020-11-02
Subject to change without notice
21
PGTPGT-08-S@SOPA S
Youcandenethefollowingparametersduringprogramming:
Parameter
DFS60B-xxPxxxxxx
DFS60B-xxMxxxxxx
DFS60A-xxPxxxxxx
DFS60A-xxMxxxxxx
DFV60A-22Pxxxxxx
DFS2xA-xxPxxxxxxxx
VFS60A-xxPxxxxxx
Description
Resolution B: 1 to
10000
A: 1 to
65536
1 to 65536 1 to 65536 1 to 65536 Denesthenumberofpulsesperrevo-
lution.
Counting direction
(CW/CCW)
X X X X Enables the signal sequence to be
changed between A before B and B
before A.
Zero pulse Width
electrical/me-
chanical
X X X X Denesthedurationofthezeropulsein
relation to a signal period (electrical) or
a revolution (mechanical) of the encoder
(type-dependent).
Electrical interface
TTL/HTL
X X X X Denestheoutputinterfacefortheincre-
mental signals.
Zero set X X X X Assigns the value 0 to the current shaft
position.
Reset to factory
settings
X X X X Resets all parameters to the factory
settings of the encoder.
b After programming, print ( ) a label with the programmed data and
stick it onto the encoder.
This means that the settings with which the encoder is being used are visible from
the outside.
Standard labels are suitable for printing.
Note:
Data entered is written to the encoder immediately and directly as long as this has not
beenalteredintheSOPASconguration(seeonlinehelp).
