10 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/TiM3xx
Please note: This documentation may contain further technical data.
10.1
Features
Variant TiM31x TiM32x TiM35x TiM36x
Measurement
principle
Type-dependent: HDDM (lower statistical error) or
HDDM+ (improved behavior for edge hits)
Application Indoor Outdoor
Light source Infrared (wavelength 850 nm, max. pulse power
880 mW, max. pulse width 5 ns, pulse frequency
550 kHz)
Infrared (wave‐
length 850 nm,
max. pulse power
880 mW, max.
pulse width 5 ns,
pulse frequency
1,500 kHz)
Laser class 1 (IEC 60825-1:2014, EN 60825-1:2014)
Complies with 21 CFR 1040.10 and 1040.11 except for the listed toleran‐
ces in the document “Laser Notice No. 50” of June 24, 2007.
Aperture angle 270°
Scanning fre‐
quency
15 Hz
Angular resolu‐
tion
1° 0.33°
Working range 0.05 m ... 4 m 0.05 m ... 10 m
Scanning range
with 10% remis‐
sion
typically 2 m typically 8 m
1
1
at ambient temperature < -15 °C: typ. 7.5 m
TECHNICAL DATA 10
8024851//2021-07-21 | SICK O P E R A T I N G I N S T R U C T I O N S | TiM3xx
51
Subject to change without notice
