10.3 Interfaces
Variant TiM31x TiM32x TiM35x TiM36x
Ethernet - TCP/IP
USB Type: Micro-USB
Function: AUX, configuration
Digital inputs 4
PNP: V
in
= max. 28 V, I
in
= max. 5 mA), opto-decoupled, debouncing time
approx. 10 ms
NPN: Common reference potential 9 ... 28 V
Digital outputs 3 (NPN, additional 1x "device ready")
Each I
out
≤ 100 mA, not electrically isolated from the supply voltage, short-
circuit proof/temperature protected
Delay time 67 ms ... 30,000 ms (can be configured)
Holding time 67 ms ... 600,052 ms (can be configured)
Optical indicators 2 LEDs (0n, output state)
10.4 Mechanics/electronics
Variant TiM31x TiM32x TiM35x TiM36x
Electrical connec‐
tion
TiM3xx-01xxxxx: Connecting cable
with open end, 15-wire
1
TiM3xx-10xxxxx: Connecting cable
with male connector, D-Sub-HD, 15-
pin
TiM3xx-11xxxxx: Connecting cable
with male connector, M12, 12-pin, A-
coded
1 x Ethernet connection, 4-pin M12
female connector
1 x voltage supply connection, 12-pin
M12 male connector
1 x micro USB female connector, type
B
Supply voltage 9 V DC ... 28 V DC
SELV and PELV acc. to IEC 60364-4-41:2005-12
Power consump‐
tion
Typ. 4 W
16 W, with 4 max. loaded digital outputs
Housing color Light blue (RAL 5012) Gray (RAL 7032)
Enclosure rating IP65
(IEC 60529:1989+AMD1:1999+
AMD2:2013)
IP67
(IEC 60529:1989+AMD1:1999
+AMD2:2013), only valid with closed
“Aux interface” plastic cover
Protection class III (IEC 61140:2016-1)
Housing Lower part: aluminum die cast
Optics cover: Polycarbonate with scratch-resistant coating
Weight 150 g, without connecting cables 250 g, without connecting cables
Dimensions (L x
W x H)
60 mm x 60 mm x 79 mm 60 mm x 60 mm x 86 mm
1
All products with the type code TiM3xx-01xxxxx are intended to be operated with open cable ends. For
production-related reasons, individual product variants with this type code are delivered with a 15-pin
D-Sub HD male connector. For these products, the customer is responsible for cutting off the male con‐
nector and creating the cable ends. Alternatively, the products may be operated with a male connector. In
this case, the information for the product variants with the type code TiM3xx-10xxxxx applies for the PIN
assignment.
