Figure 8: WTS26x-xxxxxx1xAxx, adjusting the sensing range with potentiometer
WTS26x-xxxxxx3xAxx with teach-in button:
The sensing range is adjusted by pressing the teach-in button (approx. 1-3seconds).
We recommend placing the object within the sensing range, e.g. see figure 10. Once
the sensing range has been adjusted, the object is removed from the path of the beam,
which causes the background to be suppressed. The digital output changes (table 4).
1...3 sec.
1
2
Figure 9: WTS26x-xxxxxx3xAxx, adjusting the sensing range with teach-in button
OPERATING INSTRUCTIONS
36
O P E R A T I N G I N S T R U C T I O N S | WTS26 8020355.1GI9/2022-07-13 | SICK
Subject to change without notice
en
