12 Technical data
12.1 Technical specifications
The “Technical Data” section contains only an extract of the technical data of the sensor.
The complete technical data can be found on the homepage www.sick.com under the part number of the sensor.
Features
Sensing range
WTS26P WTS26G
Min. sensing range 10 mm 10 mm
Sensing range max. 1000 mm 500 mm
Recommended sensing range for the best performance 200 mm ... 500 mm 200 mm ... 500 mm
Reference object Object with 90% remission
factor (complies with stand‐
ard white according to
DIN5033)
Object with 90% remission
factor (complies with stand‐
ard white according to
DIN5033)
Emitted beam
WTS26P WTS26G
Light sender LED LED
Type of light Visible red light Visible red light
Light spot size / distance Ø 10 mm / 550 mm 15 mm x 15 mm / 500 mm
Communication interface
Table 7: Communication interface
IO-Link
WTS26P WTS26G
IO-Link 1.1 1.1
Data transmission rate COM2 COM2
Electrical data
WTS26P WTS26G
Supply voltage U
B
DC 10 ... 30 V DC 10 ... 30 V
Ripple ≤ 5V
SS
≤ 5V
SS
Current consumption ≤30mA
1)
<50mA
2)
≤30mA
1)
<50mA
2)
Protection class III III
1)
16VDC to 30VDC, without load
2)
10VDC to 16VDC, without load
Digital output
WTS26P WTS26G
Output current I
max.
≤ 100 mA ≤ 100 mA
Circuit protection A, B, C, D
1)
A, B, C, D
1)
Response time ≤ 1.4 ms
2)
≤ 3.3 ms
2)
Switching frequency 350 Hz
3)
150 Hz
3)
1)
A = U
B
-connections reverse polarity protected
B = inputs and output reverse-polarity protected
C = Interference suppression
D = outputs overcurrent and short-circuit protected
2)
Signal transit time with resistive load in switching mode. Deviating values possible in COM2 mode.
3)
With a light/dark ratio of 1:1 in switching mode. Deviating values possible in IO-Link mode.
