SICK WTS26P User Manual

Mechanical data
WTS26P WTS26G
Enclosure rating
1)
see table 8:
x4, xH, x5, xI: IP66, IP67,
IP69
2)
x9, xB: IP65
see table 8:
x4, xH, x5, xI: IP66, IP67,
IP69
2)
x9, xB: IP65
Ambient temperature, operation –40 °C... +60 °C
3)
–40 °C ... +60 °C
3)
1)
Pursuant to EN 60529
2)
Replaces IP69K pursuant to ISO 20653: 2013-03
3)
Do not bend cables below 0°C.
12.2 Dimensional drawings
4
3
3
21.6
(0.85)
1
2
2
7.1 (0.28)
8.1 (0.32)
10.8 (0.43)
25 (0.98)
38.8 (1.53)
6.4
(0.25)
12.9
(0.51)
48.1 (1.89)
40 (1.57)
44.2 (1.74)
10
(0.39)
Ø 5.2 (0.2)
24.6 (0.97)
82.2 (3.24)
70 (2.76)
Ø 5.2 (0.2)
7.3
(0.29)
8.1 (0.32)
76.5 (3.01)
82.5 (3.25)
32.4 (1.28)
21.6
(0.85)
53.3 (2.1)
5
Figure 14: Dimensional drawing 1, cable
1
Center of optical axis, sender
2
Center of optical axis, receiver
3
Fixing hole Ø 5.2 mm
4
connection
5
Display and setting elements
M12
4
3
3
7.1 (0.28)
8.1 (0.32)
10.8 (0.43)
25 (0.98)
39 (1.54)
6.3 (0.25)
48.1 (1.89)
40 (1.57)
44.2 (1.74)
19.7
(0.78)
Ø 5.2 (0.2)
24.6 (0.97)
82.2 (3.24)
70 (2.76)
Ø 5.2 (0.2)
17
(0.67)
7.9 (0.31)
76.5 (3.01)
82.5 (3.25)
53.3 (2.1)
63.9 (2.52)
21.6
(0.85)
1
2
2
32.4 (1.28)
21.6
(0.85)
5
Figure 15: Dimensional drawing 2, male
connector
12.3 Light spot sizes
WTS26P:
0
–4
(–0.16)
–8
(–0.31)
–12
(–0.47)
4
(0.16)
8
(0.31)
12
(0.47)
0
200
(7.87)
1.000
(39.37)
1.200
(47.24)
600
(23.62)
800
(31.5)
400
(15.75)
Distance in mm (inch)
Dimensions in mm (inch)
Recommended sensing range for the best
performance
1000
(39.37)
550
(21.65)
10
(0.39)
OPERATING INSTRUCTIONS
42
O P E R A T I N G I N S T R U C T I O N S | WTS26 8020355.1GI9/2022-07-13 | SICK
Subject to change without notice
en
