Sicma CS/085 - 4 Technical Specifications

- 18 -
Tiller CS
4. TECHNICAL SPECIFICATIONS
The table below outlines the technical specications of the CS Tiller.
D
C
A
B
Machine type
CS/085 CS/105 CS/125 CS/135 CS/145 CS/165 CS/185
Tiller
Overall width (A) mm 990 1180 1330 1480 1580 1780 1980
Working width (B) mm 850 1050 1250 1350 1450 1650 1850
Height (C) mm 870
Side clearance (D) mm 715
Work depth mm 200
Weight (standard)
kg 190 210 230 248 254 276 298
lbs 418 462 506 546 559 607 656
Side transmission - Gears or chain
Rotor
Number of rotor revolutions
Revs/
min
263
Rotor pipe diameter mm 76
Rotor pipe thickness mm 8
Rotor work diameter mm 420
Number of hoes
4 hoes/
ange
16 20 24 28 28 32 36
6 hoes/
ange
24 30 36 42 42 48 54
Tractor
requisites
Tractor power min - max CV 30 - 50
Tractor hitch category cat 1st
PTO speed rpm 540
Sound level
(no-load
detection)
Acoustic pressure level dB 87.2
Sound power level dB 99.8
