CHECK THE OIL LEVEL
(Every 50 hours)
Check the oil level of the transmission unit by checking that the mark left by the
oil itself on the dipstick of the ller cap "A" is between the two reference marks
(minimum and maximum).
If it is necessary to add more oil, proceed as follows:
• Remove the oil ller cap “A”.
• Top up with AGIP-ENI BLASIA 150 type oil until the level is restored as
indicated above;
• Ret and tighten the ller cap “A”.
OIL REPLACEMENT
(The rst time after the rst 50 hours and then every 500 hours)
To replace the oil, proceed as follows:
• Unscrew the ller/vent cap “A”.
• Place a su󰀩ciently large container under the drain cap “B” (approximately 2
litres).
• Remove the cap "B" and wait for the used oil to drain completely inside the
tray.
• Reposition and tighten the drain cap “B”.
• Top up with ENI BLASIA 150 type oil until the correct level is restored
(approximately 1 litre).
• Replace and tighten the drain cap “A”.
• Dispose of the drained oil in appropriate containers for waste oils.
10.2 CONTROL AND REPLACEMENT OF THE OIL IN THE
LATERAL DRIVE SUMP
CHECK THE OIL LEVEL
(Every 50 hours)
Check the oil level in the lateral transmission casing by checking that it is visible
inside the window of the cap “C”.
If it is necessary, top up with the following steps:
• Unscrew and extract the oil ller cap “D”.
• Top up with AGIP-ENI BLASIA 150 type oil until it becomes visible from the
window of the cap “D”.
• Replace and tighten the ller cap “D”.
OIL REPLACEMENT
(The rst time after the rst 50 hours and then every 500 hours)
To change the oil, proceed as follows:
• Loosen the oil ller cap D.
• Suction the used oil from the hole in cap "D" with a dedicated pump.
• Top up AGIP-ENI BLASIA 150 type oil from the hole in cap "D" until it becomes
visible inside the window of cap "C" (approximately 1.75 litres).
• Tighten the ller cap D well.
CONTAMINATION HAZARD!
Check that there are no oil leaks and, if necessary, x them immediately.
Do not spill oil onto the ground during top-up or replacement.
WARNING!
Correctly recover the used oils and dispose of them at the appropriate
collection centres, as, according to current regulations, it must not
Max
Min
