Fig 3-28
Fig 3-29
35
(3) Email
Menu Setup Guide
Parameter Meaning
Resolution The range of options: synchronize with congured device, such as CIF
Fps The range of options: synchronize with congured device.
(Resolution and frame rate are determined by the parameter specications of
specic type)
Encode Two options: VBR and CBR
Quality The higher the grade is, the clearer the recorded image is. Six grades: lowest,
lower, low, medium, higher and highest.
Max Bitrate The range of options: synchronize with congured device, such as 32~768kbps
