Connector Pin Assignment
03621.. Connector Conductor cross-sec-
tion (solid/stranded)
Tightening torque
..11OF X24 16 mm² 1.7 to 1.8 Nm
X22A 1 to 4 mm² 0.5 to 0.6 Nm
..12EIF
X24B 2.5 to 16 mm² 1.7 to 1.8 Nm
X22A 1.5 to 4 mm² 0.5 to 0.6 Nm
..12EIC
X24B 4 to 16 mm² 1.7 to 1.8 Nm
..13CCF / DDF / EEF X22A, X22B 1 to 4 mm² 0.5 to 0.6 Nm
..13DDC / EEC X22A, X22B 1.5 to 4 mm² 0.5 to 0.6 Nm
..14EC / EF / IF X24 2.5 to 16 mm² 1.7 to 1.8 Nm
..14IC X24 6 to 16 mm² 1.7 to 1.8 Nm
..14MF / NF X24 10 to 16 mm² 1.7 to 1.8 Nm
..14QF X47 10 to 16 mm² 1.7 to 1.8 Nm
X22A 1 to 4 mm² 0.5 to 0.6 Nm
..15EIF
X24B 4 to 16 mm² 1.7 to 1.8 Nm
X22A 1.5 to 4 mm² 0.5 to 0.6 Nm
..15EIC
X24B 4 to 16 mm² 1.7 to 1.8 Nm
..30DDC / DDF / SSF X22A, X22B 1.5 to 4 mm² 0.5 to 0.6 Nm
..30SSC X22A, X22B 2.5 to 4 mm² 0.5 to 0.6 Nm
..31DDF / SSF X22A, X22B 1 to 4 mm² 0.5 to 0.6 Nm
..31DDC / SSC X22A, X22B 1.5 to 4 mm² 0.5 to 0.6 Nm
The devices 0362113xxy, 0362114xy, 0362114MF/NF, 0362114QF and 0362115xxy
are designed for usage with the following shield connection clamps. Clamps are not
part of the delivery.
Manufacturer Article number of the manu-
facturer
Description
Phoenix Contact 3025163 Shield connection clamp SK 8
(0362114QF only)
Phoenix Contact 3025176 Shield connection clamp SK 14
WAGO Innovative Connec-
tions
791-111 Shield (screen) clamp (conform to SK 14
by Phoenix Contact)
Phoenix Contact 3025189 Shield connection clamp SK 20
(0362114QF only)
WAGO Innovative Connec-
tions
791-117 Shield (screen) clamp, conform to SK 20
by Phoenix Contact (0362114QF only)
Related topics
X22/X24/X47 – Motor Phases, page 150
Motor Cable, page 170
Mounting of the Shield Connection Clamps, page 151
120 Drive System SD2 - Hardware Description
