16.2 List of the Power Supply Error Messages
Code Error message Error description Possible reason
E01 Precharge error DC link voltage The DC link could not be charged
to a minimum voltage in the defined
period of time.
▸
Mains supply too low
▸
Incorrect device parameters
(mains voltage)
▸
Short circuit in the DC link
E02 Overvoltage in DC link Too high voltage detected in the DC
link.
▸
Mains supply too high (error will
be reported on switch-on)
▸
No or defective ballast resistor
(occurs during motor decelera-
tion)
▸
Incorrect device parameters
(mains voltage)
E03 Undervoltage in DC link Too low voltage detected in the DC
link.
▸
The DC link has been overloaded
(e.g. by too high acceleration of
large masses).
▸
Mains supply is not constant.
E04 Ballast circuit load (Chopper I²t) The ballast resistor or the chopper
circuit is overloaded.
▸
Deceleration takes too long due
to large masses
▸
Incorrect parameters (ballast re-
sistor values are not accurate)
▸
No or defective ballast resistor
connected
▸
Faulty dimensioning of ballast re-
sistor (performance too low or re-
sistance not adequate)
E05 Heat sink temperature too high Heat accumulation occurred at the
heat sink of the device.
▸
Insufficient ventilation
▸
Ventilator defect
▸
Output power too high
E06 Ambient temperature too high An accumulation of heat occurred in
the device.
▸
Ambient temperature too high
▸
Insufficient ventilation
▸
Ventilator defect
E07 Short circuit in ballast circuit
or: Short circuit at precharge resistor
(only for 0362193F / 60 kW)
A short circuit occurred at the con-
nection of the ballast resistor or the
precharge resistor.
▸
Short circuit in the supply line of
the ballast resistor/precharge re-
sistor
▸
Defective ballast resistor/
precharge resistor
▸
Ballast resistor/precharge resis-
tor not suitable
E08 Loaded power supply parameters
not valid
No valid parameter set available in
the device.
▸
Device was not parameterized by
the customer (delivery is without
parameter set).
E09 Type plate missing No type plate has been loaded into
the device.
▸
Please contact SIEB & MEYER.
E10 Mains phase lost At least one input phase has been
lost.
▸
Check the power supply.
E11 Flash Error occurred in flash memory.
▸
Please contact SIEB & MEYER.
E12 Voltage rise During precharging the DC link, the
voltage was rise too low.
▸
DC link capacity defective
▸
Short circuit
▸
Wrong parameters
E13 Overvoltage Too high voltage detected in the DC
link (interrupt).
▸
Mains supply too high (error will
be reported on switch-on)
▸
No or defective ballast resistor
(occurs during motor decelera-
tion)
▸
Incorrect device parameters
(mains voltage)
