Note
Consider the order in which you connect the SD2 drive amplifiers to the PS2 power sup-
ply unit: The most powerful SD2 must be connected directly to the PS2 followed by the
next smaller SD2 devices, since the output power is reduced with each subsequent de-
vice. The maximum conductor cross-section of the used cables is 16 mm²; it can be re-
duced according to the device power.
Note
Detailed wiring examples for the connection of SD2 and PS2 as well as SD2 compact
devices (036213x) can be found in the Appendix.
Related topics
X1, X2 – 24V, page 132
X3, X4 – Bus Connection, page 132
X26/X27 – SERVOLINK, page 151
155Drive System SD2 - Hardware Description
System Connection
