3.3 Design
Synchronous/induction motors 1PH813
20 Operating Instructions, 04/2009, 610.48000.22
3.3 Design
3.3.1 Regulations
The motors comply with the following regulations acc. to IEC / EN 60034:
Table 3- 2 Regulations that have been applied
Feature Standard
Rated and operation characteristics IEC / EN 60034-1
Degree of protection
(1)
IEC / EN 60034-5
Cooling IEC / EN 60034-6
Type of construction
(1)
IEC / EN 60034-7
Noise emission IEC / EN 60034-9
Temperature monitoring IEC / EN 60034-11
Vibration severity grades IEC / EN 60034-14
(1)
The degree of protection and type of construction of the motor are stamped on its rating plate.
The three-phase motors comply with the relevant sections of EN 60034 and EN 60204-1.
Three-phase motors comply with Low-Voltage Directive 2006/95/EC. Standard motors
comply with the UL regulations. "UR" is stamped on the rating plate of these motors.
Low-voltage motors are components designed for installation in machines in accordance
with the Machinery Directive. They must not be commissioned until it has been verified that
the end product complies with this directive (also take into account EN 60204-1).
Note
Make sure that your end product is in compliance with all of the applicable legislation! The
applicable national, local, and system-specific regulations and requirements must be taken
into account.
3.3.2 Types of construction
The motor is available in the following basic types of construction as well as other optional
types of construction with further potential applications.
Table 3- 3 Types of construction
Shaft height Standard type of construction Rotated type of construction
IM B3 IM V5, IM V6
IM B5 IM V1, IM V3
1PH813□
IM B35 IM V15, IM V36
Two lifting eyebolts, which can be screwed onto the motor in accordance with its type of
construction, are supplied with the motor for transportation purposes.
