Connection
6.2 Electrical connection
Synchronous/induction motors 1PH813
38 Operating Instructions, 04/2009, 610.48000.22
DANGER
Risk of electric shock
The insulating film in the terminal box protects against voltage flashover to the cover and
must not be removed.
CAUTION
Electrostatically-sensitive devices
The DRIVE-CLiQ interface contains electrostatically-sensitive components. Touching
connections with electrostatically charged hands or tools can cause malfunctions.
Note the ESD protection measures.
6.2.2 Cable entry and routing
When selecting the required connecting cables, make sure that you take into account the
rated current and plant-specific conditions, such as ambient temperature, routing type,
etc. according to IEC / EN 60364-5-52 and IEC / EN 60204-1.
Use EMC cable glands for permanently installed cable entries.
Use shielded cables whose shields are conductively connected to a large area of the
terminal box of the motor via EMC cable glands.
Arrange the exposed connecting cables in the terminal box so that the PE conductor has
an excess length and the insulation of the cable conductors cannot be damaged.
Only remove insulation from the cable ends so that the insulation reaches up to the cable
lug, terminal, or wire end ferrule.
Adapt the size of the cable lugs or wire end ferrules in line with the dimensions of the
terminal board connections and the cross-section of the power cable (use parallel
connection cables, if necessary).
Make sure that the inside of the terminal box or connector is clean and free of cable
cuttings and moisture.
Tighten all of the screws for the electrical connections (terminal board connections, with
the exception of the terminal strips) to the specified torque:
