Siemens 6 Series User Manual

Compact Operating Instructions in accordance with EN 61010-1 and EN 60079-0
A5E45779144002-01, 09/2018
21
CALOMAT 6E
When installing in a cabinet, mount analyzer on support rails or telescopic rails
1
RS485 9-pin connector
2
15-pin connector, relay outputs and binary inputs
3
25-pin connector, analog inputs and outputs
4
9-pin interface connector for PROFIBUS (option)
5 37-pin connector, relay outputs and binary inputs
(option)
6 Network connection and fine fuses
Figure 4-9 CALOMAT 6E, gas connections and electrical connections
5
Commissioning
5.1
Safety instructions
WARNING
Hazardous contact voltage
Risk of injury through hazardous contact voltage when the device is open or not completely closed.
The degree of protection specified on the nameplate or in Technical specifications (Page 26) is no longer guaranteed if the
device is open or not properly closed.
•
Make sure that the device is securely closed.
CAUTION
Loss of degree of protection
Damage to device if the enclosure is open or not properly closed. The degree of protection specified on the nameplate or in
Chapter "Technical specifications (Page 26)" is no longer guaranteed.
•
Make sure that the device is securely closed.
