Siemens 6 Series User Manual

Compact Operating Instructions in accordance with EN 61010-1 and EN 60079-0
32 A5E45779144002-01, 09/2018
Parts in gas path wetted by sample gas
Gas connections
Stainless steel 1.4571, pipe diameter 1/4" or 6 mm
Gaskets (O–rings)
FFKM (e.g. Chemraz)
Sensor
Silicon, SiO
x
N
y
, gold, epoxy resin, glass
Measuring cell body
Stainless steel 1.4571
Internal gas path (gas lines)
Stainless steel 1.4571
Leak-tightness
Loss through leaks < 0.5 μl/s
Gas inlet conditions
Permissible sample gas pressure
800 to 1100 hPa absolute
Sample gas flow
30 to 90 l/h (0.5 to 1.5 l/min)
Sample gas temperature
0 to 50 °C
Sample gas humidity
< 90% RH (relative humidity), non-condensing
7.7
Technical specifications CALOMAT 62E
Enclosure
Weight
Approx. 13 kg
Dimensions
383 x 177 x 390 mm
Electrical characteristics
Power consumption (unit)
Approx. 30 VA
Fuse values
• 100 ... 120 V
• 200 ... 240 V
T1L250V
T630L250V
Gas path
Gas connections
Female thread 1/8"-27 NPT (according to ANSI B 1.20.1)
Gaskets (O–rings)
FKM (e.g. Viton) or FFKM (e.g. Kalrez)
Sensor
Glass
Internal gas path (gas lines)
Stainless steel 1.4571
Leak-tightness
Loss through leaks < 0.5 μl/s
Gas inlet conditions
Sample gas pressure
800...1100 hPa (absolute)
Sample gas flow
30...90 l/h (0.5...1.5 l/min)
Sample gas temperature 0 to 50 °C
Sample gas moisture content < 90% RH
Time response
Warm-up time
< 30 min, maximum accuracy is achieved after about 2 hours
Delayed display T
90
(incl. dead time)
Approx. 35 s
Damping (electronic time constant)
0 to 100 s, adjustable
Dead time (at 1 l/min)
Approx. 34 s (because of diffusion to sensor)
