Operating manual PA
101
36.2 Configuration I/O (configuration layer: C010)
Parameter
Function
Default
User settings
AO1.S
Ao1 select source
Lamda 1
AO1._
Ao1 define lower limit of
temp. span
Measuring range
begin
AO1.~
Ao1 define upper limit of
temp. span
Measuring range
end
AO1.4
Ao1 0/4 - 20mA
4 – 20 mA
AO2.
Analogausgang 2
Off
AO2.S
Ao2 select source
--
AO2._
Ao2 define lower limit of
temp. span
--
AO2.~
Ao2 define upper limit of
temp. span
--
AO2.4
Ao2 0 / 4 - 20mA
--
DO1.
Switching output 1
On
DO1.S
Do1 select source
Status Ready sig-
nal
DO1.F
Do1 function
Level/signal
DO1.T
Do 1 switching
threshold
--
DO1.H
Do1 signal threshold
--
DO1._
Do1 lower limit of range
--
DO1.~
Do1 upper limit of range
--
DO1.L
Do1 delay time
0.00 s
DO1.M
Do1 Hold time
0.00 s
DO2.
Switching output 2
Off
DO2.S
Do2 select source
--
DO2.F
Do2 function
--
DO2.T
Do 2 switching
threshold
--
DO2.H
Do2 signal threshold
--
DO2._
Do2 lower limit of range
--
DO2.~
Do2 upper limit of range
--
DO2.L
Do2 delay time
--
DO2.M
Do2 Hold time
--
AI.FN
Analogue input function
--
AI.U1
Analogue in upper and
lower voltage values
--
AI.U2
Analogue in upper and
lower input variables
--
AI.V1
Analogue in upper and
lower input variables
--
AI.V2
Analogue in upper and
lower input variables
--
SAVE
Save
ESC
Escape
