1. Press the MODE button while in normal operating mode to switch
to "configuration layer" mode.
2. Use ▲▼ to select the configuration layer for the parameter you
wish to set.
3. Press MODE to confirm. Press ▲▼ to select the particular pa-
rameter.
4. Press MODE to confirm. Press ▲▼ to adjust the parameter val-
ue.
5. Press MODE again to end. Press ▲▼ to select END/SAVE.
6. Now use MODE to either apply the changes you have made to the
settings [SAVE] or to close without saving these changes
[END] . After that, the display panel will resume showing the
temperature reading.
The following parameters are important for initial set-up prior to first-time
operation. See Chapter 6 for a comprehensive list of all adjustable pa-
rameters.
Parameter
configuration
layer
Explanation
EPS.1
C001
Emissivity spectral channel 1
(see chapter 6.7).
AO1._
C010
Lower limit of temperature span
analogue output Ao1
(see chapter 6.8).
AO1.~
C010
Upper limit of temperature span
analogue output Ao1
(see chapter 6.8).
AO1.4
C010
Hardware configuration of the ana-
logue output 0-20 mA, 4-20 mA
(see chapter 6.8)
AO1.T
C100
Temperature measurement simula-
tion to verify signal transmission
(see chapter 6.9)
NOTE !
Key lock may have been activated at the terminal. When selecting
the configuration layer you will be prompted to enter an access
code with P000 . To obtain full access to parameter settings,
enter P100 otherwise you will only be able to view parameters
but not change them.
6.7 Setting Emissivity
