Operating manual PA
34
ON simple smoothing
AUTO subsequent smoothing (only model PA1x)
FIL.T
Smoothing time
time t98 in sec.for simple smoothing
MEM.1
Min/Max memory
OFF off
MIN lowest (min.)temperature, single
MAX highest (max.) temperature, single
DBL.M double maximum
DIS.M ATD function in process
MEM.T
Hold time for
Min/Max
Hold time in sec.
FIL.M
Smoothing filter for
min/max *
OFF Off
ON On
FIL.T
Smoothing time*
Time t98 in sec.
CLR.M
external delete for
Min/Max memory*
OFF no external deletion
EXT.1 delete when 0-24V for switching output 1
EXT.2 delete when 0-24V for switching output 1
T.DEL
time delay**
For ATD function, see Chap. 7
T.ACT
meas. time active**
For ATD function, see Chap. 7
T.DIS
cut-off interval**
For ATD function, see Chap. 7
T.OUT
timeout**
For ATD function, see Chap. 7
LI. 1
Limit 1**
For ATD function, see Chap. 7
LI. 2
Limit 2**
For ATD function, see Chap. 7
F-PR
Average weighting**
For ATD function, see Chap. 7
TSP_
Threshold plausibili-
ty**
For ATD function, see Chap. 7
TSP~
Threshold plausibili-
ty**
For ATD function, see Chap. 7
ANO
Mode of display**
T=0 show lower limit of temp. range during
running measurement
T.HLD Hold previous temp. reading during run-
ning measurement
A.RST
Autoreset**
For ATD function, see Chap 7
CH.L.2
Set Li2 check on
tAct**
For ATD function, see Chap 7
SAVE
Save
Save changes / exit menu
ESC
Escape
Discard changes / exit menu
* Only available with Min/Max and Double Max modes
** Only available with ATD function
NOTE !
L1 stands for Lambda 1, meaning the temperature reading from
spectral channel 1
