42 WLAN Configuration
DRAFT 22.04.2008
ARCADIS SP00-000.814.09.01.02 Siemens
11.07 CS PS SP
Page 42 of 78
Medical Solutions
• Click on the + symbol to the left, next to the network that was found.
¹ The line "Ind. Ethernet Interface" appears.
Fig. 40: WLAN Client network configuration
• Highlight the "Ind. Ethernet Interface" line by clicking on it.
¹ The Ethernet interface configurations for the WLAN Client are displayed.
• Click on “Assign IP parameters”.
• The IP address defined by the customer's network administrator and the Subnet mask
for the WLAN Client must be entered.
NOTE
To administer the WLAN Client, a permanent IP address /
Subnet mask must be assigned to it.
The image system PC and the WLAN Client must be operat-
ing in the same network segment.
• Click on the line "INC : XX-XX-XX-XX-XX-XX : YYY.YYY.YYY.YYY".
¹ The line is highlighted in color.
NOTE
XX-XX-XX-XX-XX-XX corresponds to the WLAN Client MAC
address.
YYY.YYY.YYY.YYY corresponds to the current IP address of
the WLAN Client.
If the line is not selected, the menus under "Module" cannot
be selected.
