Siemens CCAW1417-LPO

Technical data
10
Siemens AG 03.2011
Scanning frequency 15.625 kHz (H), 50 Hz (V)
Synchronization Internal/external: line lock
Horizontal resolution Colour: 560 TV lines
B/W: 600 TV lines
Min. illumination
Colour: 0.5 lux
B/W: 0.05 lux
Slow shutter: 0.001 lux
0.5 lux at F=1.6 (AGC on, 50 IRE video output)
Video output 1.0 Vpp (75 Ω, composite)
Signal/noise ratio 50 dB (AGC off)
Functions
Wide dynamic range (WDR) On/Off/Level (x512, 48 dB)
Back light compensation (BLC) Auto/Manual (Area, Level)/Off
Day/night Colour/BW/Auto/EXT
Motion detection (MD) On/Off (Area/Sensitivity setting)
Slow-speed shutter 2x – 128x
Digital noise reduction (DNR) 2D/3D
Face detection (FD)
On/Off
Privacy masking (PM) Max. 16 zones, mosaic function
White balance (WB) AWB/WAWB/Indoor/Outdoor/Manual/CRS
(Colour Rolling Suppression)
Auto exposure (AE) Auto1/Auto2/Shutter Priority/Manual
Iris control Automatic
Automatic gain control (AGC) MIN/LOW/MID/HIGH (max. 30 dB)
Shutter speed Normal: 1/100.000
Title A – Z / 0 – 9
Display On/Off/Push On (DISP1/DISP2)
Brightness Adjustable in steps from 10 - 50
Sharpness Adjustable in steps from 0 - 15
Zoom presets 10
Zoom tour 1 tour / 10 presets
Alarm mode On/Off/Dwell Time
Remote configuration RS-232: Siemens B (parameter setting)
RS-485: Siemens B, S; Molynx; Pelco D, P
Bit rate BPS 2400/4800/9600/19200
Camera ID 1 – 255
Effect Sharpness, Nega/Posi, D-FLIP, Freeze, HI-
RES, 2-3 DNR
Home preset Off/Home Preset Select/Dwell Time
Lens
Focus mode Auto/Manual/Push AF
Distance 0.1 m/1.0 m/1.5 m/2.5 m/6.0 m
Total zoom 22x optical zoom, 16x digital zoom (video AF)
Focal length 3.9 – 85.8 mm
