Siemens CCAW1417-LPO

System installation
16
Siemens AG 03.2011
Typical system configuration with directly controlled cameras
1
1
.....
C1
C2
C10
2
3
33
B
B
B
A
1 Camera C1..C10 A RS485
2 Keyboard B Video
3 Monitor
7.2 Installation
Mounting variations:
1234
Fig. 5 Mounting
1. Cable routing through the wall using the mounting base.
2. Cable through the conduit knockout in the mounting base.
3. Cable through the cable gland without using the mounting base.
4. Cable routing into the installation box (optional).
