Camera settings
26
Siemens AG 03.2011
SET PRESET Select zoom position of zoom preset
TOUR CONFIG Select ENTER to save the tour configuration (preset combination)
HOME PRESET Home preset on/off
HOME WAIT Waiting time after which the camera returns to start position (HOME PRESET)
END Back to the next higher menu level
Move the cursor using the "Far/Near", "Tele/Wide" keys.
Press MENU to enter the next level for configuration.
12
<TOUR CONFIG MENU>
01* 02* 03 04 05
06 07 08 09 10
< S E
DWELL TIME 010
CMD description
* : User-saved preset
< : Deletes the character at the cursor position and
moves one position to the left
S : Save the present tour setting
E : Exit
DWELL TIME
Zoom preset dwell time (10 – 180 s)
When ZOOM PRESET is selected, you can adjust the preset zoom location using the “tele” and “wide”
buttons.
When a ZOOM PRESET has been selected press the MENU button to save the preset.
9.2.2 WB (White Balance)
<WB MENU>
MODE
R GAIN
B GAIN
FRAME ADJ
END
MODE WB modes:
z AWB: Auto White Balance: 2500K – 9500K
z WAWB: Wide Auto White Balance: 1800K – 10500K
z INDOOR: Indoor white balance mode
z OUTDOOR: Outdoor white balance mode
z MANUAL: You can change R and B gain manually
z CRS (Colour Rolling Suppression): Decrease colour rolling effect; useful in
SHUTTER mode in AE menu
R GAIN Adjust red gain: 0 – 255
B GAIN Adjust blue gain: 0 – 255
FRAME ADJ Since the colour rolling path differs depending on the fluorescent lamp used, it
has to be adjusted individually. To do so, select the WB menu.
After about 10 s, the adjust mode will be finished automatically.
END Back to the next higher menu level
