Camera settings
27
Siemens AG 03.2011
9.2.3 AE (Auto Exposure)
<AE MENU>
MODE
SHUTTER
GAIN
DSS
MAX DSS
FLICKERLESS
BRIGHTNESS
END
MODE AE modes:
z Auto1: For use in normal environments: Indoor (shutter speed 1/50 s)
z Auto2: For use in high-brightness environments: Outdoors
z Shutter Pri.: Shutter priority exposure mode
z Manual: Manual exposure mode
SHUTTER Select shutter speed: 1/50 – 1/100 000 s
Can be changed while in "Shutter Pri" and "Manual" mode
GAIN Select maximum Auto Gain Control (AGC) value
DSS Digital slow shutter on/off (enable in low light)
MAX DSS Select digital slow shutter range: x2 – x128
FLICKERLESS Flicker-less function on/off
BRIGHTNESS Select brightness level: 10 – 50
END Back to the next higher menu level
9.2.4 BLC / WDR (Back Light Compensation / Wide Dynamic Range)
<BLC/WDR MENU>
BLC MODE
AREA
LEVEL
WDR MODE
LEVEL
END
1 2 3
4 5 6
7 8 9
<BLC area number>
BLC MODE BLC mode: OFF, AUTO, MANUAL:
AUTO: Automatic back light compensation (area & level)
MANUAL: Back light compensation (area & level reserved)
BLC AREA Select BLC area: 1-9, activated only in BLC manual mode
BLC LEVEL Select back light compensation level: LOW, MID, HIGH
WDR MODE WDR (Wide Dynamic Range) function on/off
WDR LEVEL Select WDR level: 10 – 50
END Back to the next higher menu level
