2 Engineering
Ethernet Communication (ISO on TCP) between SIMATIC S5 and
SIMATIC S7-1500 Controllers
Entry-ID: 109482475, V1.2, 07/2019
16
© Siemens AG
2019 All rights reserved
2.1.5 SIMATIC S5 application software
STEP 5 project files
The example project for the SIMATIC S5 includes
• the program for the CPU 944 (AG115@ST.s5d)
• the configuration file for the CP1430 TCP (TCP1430A.TCP)
The configuration file TCP1430A.TCP for the CP1430 TCP is structured in such a
way that all required connection information is completely configured and
functionally available for all example scenarios listed in Table 2-4.
The example program for the SIMATIC S5-CPU contains all user programs for all
scenarios. The example scenarios listed in Table 2-4 can be enabled individually in
the S5-CPU via the corresponding enable bits.
