2.10 Operating the Application
The following chapter describes the operation as well as the test and diagnostic
functions of the different scenarios.
Prerequisites
The SIMATIC S5-CPU program and the CP1430 TCP connection configuration
include all example scenarios. The required S5 program blocks and the
corresponding functions are enabled via enable bits after loading the S5 program.
For successfully testing a scenario,
• the corresponding enable bit in the SIMATIC S5-CPU must be set,
• the corresponding SIMATIC S7-1500 station must be loaded,
• the corresponding enable bit in the SIMATIC S7-CPU must be set where
necessary.
Table 2-28
Scen.
S5-CPU
enable bit
S7-CPU
Enable bit
S7 station name
Description
1
M 130.5
-
PLC_Sz1_F-W_S5-
CP1430TCP
Communication via FETCH/WRITE
and CP1543-1
2a
M 130.3
E 0.1
PLC_Sz2_S-
R_CPU_ID5_ID105
Communication via programmed
Open User Communication (single
instruction) and internal CPU interface
2b
M 130.4
E 0.2
Communication via parameterized
Open User Communication (single
instruction) and internal CPU interface
3
M 130.2
E 0.1
PLC_Sz3_S-
R_CP_TRCV_C_ID7
Communication via programmed
Open User Communication (compact
instruction) and CP1543-1
4a
M 130.0
E 0.1
PLC_Sz4_S-
R_CP_ID4_ID104
Communication via programmed
Open User Communication (single
instructions) and CP1543-1
4b
M 130.1
E 0.2
Communication via parameterized
Open User Communication (single
instructions) and CP1543-1
5
M 130.6
E 0.1
PLC_Sz5_S-
R_CPU_TSEND_C_I
D6
Communication via programmed
Open User Communication (compact
instruction) and internal CPU interface
