2 Engineering
Ethernet Communication (ISO on TCP) between SIMATIC S5 and
SIMATIC S7-1500 Controllers
Entry-ID: 109482475, V1.2, 07/2019
77
© Siemens AG
2019 All rights reserved
Function
The OUC block TSEND_C is used to actively establish a connection via the
integrated PNIO interface of the CPU by calling the FB 6
(ConnManagerParamID6). As soon as the connection is established, the data are
exchanged via the communication blocks TSEND_C and TRCV.
Via the connection, data are sent bidirectionally with a count value from the
SIMATIC S5 to the S7-1500 every second. From there, this count value is mirrored
and sent back. After the data have been received, this count value is increased by
+1 and sent again.
Note
The mixed variant of the OUC blocks TSEND_C (compact instruction) and TRCV
(single instruction) used in this example scenario is recommended, if only one
connection ID shall be used for sending and receiving the data.
Further details and information concerning this mixed operation are given in the
following entry (109479564).
Block
Symbol
Description
OB 100
Startup
Startup OB
OB 1
Main
Cyclic OB
FB 6
ConnManagerProgID6
Management TSEND_C ID 6
DB 35
InstConnManagerProgID6
DB 25
ConnectParamID6
Connect parameter ID 6
DB 4
InstTSEND_C_ID6
Instance DB TSEND_C ID 6
DB 3
InstTRCV_ID6
Instance DB TRCV ID 6
DB 100
ParaDbID6_TSEND_C
Parameter DB TSEND_C
DB 200
ParaDbID6_TRCV
Parameter DB TRCV
DB 110
DataTSEND_C
Send data area
DB 210
DataTRCV
Receive data area
