Pan/Tilt and Telemetry Equipment
Pan/Tilt Telemetry Receivers / Drivers
4-9© Siemens Building Technologies Group
4
Type Order No.
RX210-HS01
A RX210‚ but Suitable for HS01 Mounting
RX210 board mounted on a chassis to install in a HS01 housings.
Power requirements 230 D 240 V AC‚ 50/60 Hz
Power consumption 20 W
P/T head control voltage 230 V AC
Address codes 256
Dimensions (W x H x D) 102 x 30 x 100 mm
Telemetry formats C Type (Coax) or
D Type (RS485‚ Molynx protocol)
Baud rate 9600 bps
MTBF At 25° C 30‚000 h
Dimensions (W x H x D) 102 x 30 x 100 mm
Control functions 10
Compatible with Controllers / matrix switchers with
Molynx protocol
Operating temperature range -20° C to +40° C
Weight PCB: 0.80 kg
Box: 1.50 kg
BPZ:80-201
RX210-PCBCD/D12
10 Function Telemetry Receiver Board
RX210 board only‚ for use in applications where a customer-specific
enclosure or other installation is to be used.
Power requirements 12 V DC
Power consumption 20 W
P/T head control voltage User preferency (24 V AC‚ 230 V AC)
Address codes 256
Dimensions (W x H x D) 102 x 30 x 100 mm
Telemetry formats C Type (Coax) or
D Type (RS485‚ Molynx protocol)
Baud rate 9600 bps
MTBF At 25° C 30‚000 h
Dimensions (W x H x D) 102 x 30 x 100 mm
Control functions 10
Compatible with Controllers / matrix switchers with
Molynx protocol
Operating temperature range -20° C to +40° C
Weight 0.26 kg
BPZ:80-202
