Technical data
12.2 Technical data, Power Modules
Inverter with CU230P-2 Control Units
390 Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
380 V ... 480 V 3-ph. AC ± 10%
0 V 3-ph. AC … input voltage x 0.95 (max.)
0 … 650 Hz, depending on the control mode
Less than the input current
Pulse frequency (factory
setting)
4 kHz for 0.37 kW ... 90 kW
2 kHz for 110 kW ... 250 kW
The pulse frequency can be increased in 2 kHz steps. An increase in the pulse frequency
results in a lower output current.
Electromagnetic
The devices in compliance with EN 61800-3: 2004 are suitable for Category C1 and C2
environments. For details, see the Hardware Installation Manual, Appendix A2
DC braking, compound braking, dynamic braking with integrated braking chopper
Operating temperature LO without derating:
HO without derating:
HO without derating:
all power ratings
0.37 ... 110 kW
132 … 200 kW
0 °C … +40 °C
0 °C … +50 °C
0 °C … +40 °C
For details, see the
Hardware Installation
Manual.
Protected according to pollution degree 2 to EN 61800-5-1: 2007
< 95% - condensation not permissible
Environmental requirements Protected against damaging chemical substances according to environmental class 3C2 to
Shock and vibration
• Long-term storage in the transport packaging according to Class 1M2 to EN 60721-3-1:
1997
• Transport in the transport packaging according to Class 2M3 to EN 60721-3-2: 1997
• Vibration during operation according to Class 3M2 to EN 60721-3-3: 1995
Installation altitude without derating:
0.37 kW ... 132 kW
160 kW ... 250 kW
up to 1000 m above sea level
up to 2000 m above sea level
up to 4000 m above sea level
For details, see the
Hardware
Standards UL, cUL, CE, C-tick, SEMI F47
The drive only satisfies the UL requirements when UL-certified fuses are used.
