PMI OPERATION MANUAL | CHAPTER 3
MAINTENANCE MODE3-8
Maint:Control:Arm:Settings
PHY:FireFinder@1, DLC@1, HFP11@2
Apply To
Components
Cancel OK
Inputs
Switch 1
Neural
Devices
Smoke/Photo
Thermal
Outputs
Switch 2
Figure 3-12
Arm Inputs Settings
Inputs When the Inputs box is selected, the components section of the screen displays the
items that can be chosen. Items that can not be chosen are grayed out. (In Figure
3-12, Switch 1 and Switch 2 are grayed out.) Make a selection of the components you
wish to arm, then press the OK soft key.
At this point, the components that were selected are not yet armed.
The Arm Inputs status screen displays. See Figure 3-13. The components that were
chosen are now listed in the Components section of the screen. In this example, they
are Smoke/Photo, Thermal. Press the Execute soft key to arm the selected components.
Menu:Maint:Control:Arm
PHY:FireFinder@1, DLC@1, HFP11@2
ARM INPUTS
AT: FireFinder@1, DLC@1, HFP11@2
Cancel Settings Execute
COMPONENTS: Smoke/Photo, Thermal
Figure 3-13
Arming Selected Inputs
Outputs When the box labeled Outputs is selected, the components section of the screen
displays the items that can be chosen. See Figure 3-14. Items that can not be chosen
are grayed out. (In Figure 3-14, Relay 2, LED, and Status LED are grayed out.) Make a
selection of the components you wish to arm, then press the OK soft key.
