CHAPTER 3 | PMI OPERATION MANUAL
MAINTENANCE MODE 3-9
Menu:Maint:Control:Arm:Settings
PHY:FireFinder@1, DLC@1, HFP11@2
Apply To
Components
Cancel OK
Inputs
Relay 2
Status LED
Devices
Relay 1
LED
Outputs
Figure 3-14
Arm Outputs Settings
At this point, the components that were selected are not yet armed.
The Arm Outputs status screen returns. See Figure 3-15. This time the components
that were selected are listed in the Components section of the screen. In this
example, the component is Relay 1. Press the Execute soft key to arm the selected
component.
Menu:Maint:Control:Arm
PHY:FireFinder@1, DLC@1, HFP11@2
Cancel Settings Execute
ARM OUTPUTS
AT: FireFinder@1, DLC@1, HFP11@2
COMPONENTS: Relay 1
Figure 3-15
Arming Selected Outputs
Control - ASD While in the Maintenance mode, navigate to the desired module/loop or device by
pressing the More Info +/- buttons.
Change ASD can only be performed at the device level (Physical view) and Bypass
ASD can only be performed at the module (DLC) level. These operations will appear
grayed out on the PMI when the system is set at any other level.
Press the Control soft key. [If the appropriate level password has not been previously
entered or if it has timed out, the Enter Password screen displays. (See page 3-1.)]
The Control menu displays. Touch the desired operation to either bypass, enable or
change the ASD setting.
