LED Color Function Condition Meaning
RX2 Green Receiving data from fiber-
optic circuit'2'
Lit up Data is being received from circuit'2'
Power B Green Supervision of feeding voltage
for 'Power B'
On Normal operation (feeding voltage
available)
Off No feeding voltage or voltage below
minimum input voltage (9V)
Power A Green Supervision of feeding voltage
for 'Power A'
On Normal operation (feeding voltage
available)
Off No feeding voltage or voltage below
minimum input voltage (9V)
LNK1 Green Data transmission HNET/
XNET/HUB-4/SNC - circuit'1'
Flashes Data is being transmitted via A1/B1
EF1 Yellow Off Not used
EF2 Yellow Off Not used
LNK2 Green Data transmission HNET/
XNET/HUB-4/SNC - circuit'2'
Flashes Data is being transmitted via A2/B2
1.6 Technical data
Supply input Input voltage DC24V
Decentralized mounting Shielded supply cable (not in scope of
supply)
Operating current Max. 132mA@DC24V
Supervision contact Do not use -
Fibre optic cable Type of connection SC connector
Cable end box Standard 'PC' or 8° polish 'APC'
Wavelength 1310nm (for MM and SM)
FN2014-U1 Multi-mode
Range:
Fiber type 62.5/125µm 13100ft/4000m
Fiber type 50/125µm 6550ft/2000m
Optical budget:
Fiber type 62.5/125µm 11dBm
Fiber type 50/125µm 7.5dBm
Fiber network module FN2013/FN2014
Technical data
1
18 | 28 2023-01-23 A6V12093642_en--_b
