Siemens LMV3 series - Flame Scanner Accessories

Technical Instructions LMV Series
Document No. LV3-1000
Section 1 Page 12 SCC Inc.
Flame Scanner Accessories
QRA4… Accessories – Optional
Mounting accessories are available for the QRA4… flame scanners. For more information, refer
to Document No. N7711.
THERMAL-
75X75
Thermal barrier for use with the QRA4… flame
scanners. Adapts a 3/4” NPSM thread to a female
3/4” NPT connection. Rated for scanner tube
temperatures up to 280 °F
AGG02
Heat insulating lens with spring washer and O-ring,
for applications where the temperature at the
scanner will exceed 176 °F, to be mounted inside
thermal barrier THERMAL-75X75
ACS410 Software for Laptop
The ACS410 software for the LMV3 offers many features including parameter backups, startup
reports, and trending. The software may be downloaded at www.scccombustion.com.
ACS410 Cables – Qty (1) Required if Using the ACS410 Software
To use the ACS410 software, cables are necessary to connect the LMV3 to a PC.
OCI410.20
User-level PC interface module and cable. Permits
access to user level parameters only without the
ability to perform parameter backups
OCI410.30
Service-level PC interface module and cable.
Permits access to user and service level parameters
and the ability to perform parameter backups
OCI410.40
OEM-level PC interface module and cable. Permits
access to all parameters and the ability to perform
parameter backups
