Siemens LMV3 series User Manual

LMV Series Technical Instructions
Document No. LV3-1000
SCC Inc. Page 15 Section 1
Description Part Number Qty
Gas Firing Rate
Control Valve
Valve Actuator Assemblies
(Qty 1 Required if Firing Gas)
Write in part number
(See Doc. No. VA-1000 or VA-3000)
Oil Firing Rate
Control Valve
Valve Actuator Assemblies
(Qty 1 Required if Firing Oil and Not Using a
Cleaver Brooks Oil Valve)
Write in part number
(see Doc. No. VA-4000)
Cleaver Brooks Retrofit Kits
(Optional)
Retrofit kit for SQM33
(See Doc. VA-5000)
BR-45CBOIL
Actuator Accessories
NEMA 4 Kits
(Optional)
NEMA 4 kit for SQM33 actuators BR-N4-SQM33
Plug Adapters
(Optional)
Plug adapter for air actuator
ADP
-
SQM33
-
RAST2.5
-
3.5-AIR
Plug adapter for fuel actuator
ADP
-
SQM33
-
RAST2.5
-
3.5-FUEL
VFDs
Variable Frequency Drives, Brake Resistors,
Line/Load Reactors (Optional)
Write in part number
(Contact SCC)
Speed Sensor Kits
(Qty 1 Required per VFD)
Speed sensor kit for conduit AGG5.305
Speed sensor kit w/o conduit AGG5.310
Flame Scanner
Flame Scanners
(Qty 1 Required)
UV forward view (non self-check) QRA4.U
UV forward view (non self-check; high
sensitivity)
QRA4M.U
Flame Scanner Accessories
(Optional)
3/4" NPT thermal barrier
(rated for 280°F)
THERMAL-75X75
Heat insulating glass AGG02
ACS410 Software
PC Interface
(Optional)
ACS410 software
Download free at
www.scccombustion.com
User cable to connect LMV to PC OCI410.20
Service cable to connect LMV to PC OCI410.30
OEM cable to connect LMV to PC OCI410.40
