LMV Series
Technical Instructions
LV3-1000
Gas Oil Gas Oil U/S/O Default Range Description
Service Level PW 9876
Any 4
characters
The service level password can be changed here. It must be exactly 4 characters in length. Enter the same
password twice to change it (n = new, r = repeat).
OEM Level PW EntrY
Any 5
characters
The OEM level password can be changed here. It must be exactly 5 characters in length. Enter the same
password twice to change it (n = new, r = repeat).
Backup / Restore
Backup - 0
Restore - 0
-99-50
Used to perform parameter backups and restores.
Backup: LMV3 transfer to AZL. Restore: AZL transfer to LMV3.
Set parameter to 1 and press Enter to begin the backup or restore. When the value changes back to 0, the
backup or restore was completed successfully. If the value changes to any other number besides 0, see
error code 137 for the cause of the failure.
Burner ID AZL Burner ID of the LMV3 parameter set currently stored in the AZL.
AZL Parameter Set
Associated ASN
Coded LMV3 part number (ASN) associated with the parameter set currently stored in the AZL.
Code example for an LMV37.420A1:
056.00 = 3, 056.01 = 7, 056.02 = 4, 056.03 = 2, 056.04 = 0, 056.05 = 1.
AZL Parameter Set
Associated SW
Software version of the LMV3 associated with the parameter set stored in the AZL.
Production Date Date that the LMV3 was produced in the DD.MM.YY format.
Serial Number Serial number of the LMV3.
Default Parameter
Set Code
Parameter set code for the default parameters.
Default Parameter
Set Version
Version (revision) of the default parameter set.
LMV3 SW Version Factory loaded LMV3 software version.
LMV3 SW Variant Factory loaded LMV3 software variant.
Parameter Set Code
LMV3
S
Coded LMV3 part number (ASN). For comparison to parameter 056.
Code example for an LMV37.420A1:
056.00 = 3, 056.01 = 7, 056.02 = 4, 056.03 = 2, 056.04 = 0, 056.05 = 1.
Burner ID LMV3 U/S Not set 0-99999999
The burner ID is set here. The burner ID must be all digits (no letters), from 1-8 digits in length. Typically
the burner / boiler serial number is used. This serves as an identifier for the parameter set. The burner ID
must be set in order to perform a parameter backup.
111
105
Read only
102
113
041
042
107
108
LEGEND - Password Access: U = User, S = Service, O = OEM, U/S = View - User, Write - Service, S/O = View - Service, Write - OEM
Shaded Parameters = Frequently Used. ** Parameters = Must Set. Fuel 1 parameters for LMV36 only.
100 Level: General Information / Configuration / Modbus
U
To Next Page
