LEGEND - Password Access: U = User, S = Service, O = OEM, U/S = View - User, Write - Service, S/O = View - Service, Write - OEM
Shaded Parameters = Frequently Used. ** Parameters = Must Set. Fuel 1 parameters for LMV36 only.
Parameter Name
Revert To Pilot S/O 0 0-2
Parameter only exists on an LMV37: This enables or disables the "revert to pilot" function. When the
"revert to pilot" function is enabled, load controller input X5-03.3 is no longer used and input X5-03.2 is re-
purposed as the input signal for the "revert to pilot" function. See Appendix A for a detailed guide on the
"revert to pilot" function.
0 = disabled
1 = enabled when input X5-03.2 is de-energized
2 = enabled when input X5-03.2 is energized
Revert Min 30 sec 5-120 sec
Parameter only exists on an LMV37: When using the "revert to pilot" function, this sets the minimum time
the LMV3 will run on the pilot only before switching back to the main valves, even if the signal on input X5-
03.2 is calling for the main valves to open before this time expires.
Revert Max 3600 sec 30-6480 sec
Parameter only exists on an LMV37: When using the "revert to pilot" function, this sets the maximum time
the LMV3 will run on the pilot only without receiving a signal on input X5-03.2 to switch back to the main
valves before turning the burner off.
Repetition Safe 1 O 1 1-4
ignition or main trial for ignition. After this number of tries, a lockout will occur.
Repetition HO S 3 1-16
Parameter only exists on an LMV37: Sets the number of times the LMV3 will attempt to start up if a start
release for heavy oil is not met on input X9-04.2. After this number of tries, a lockout will occur. A setting
of 16 indicates unlimited repetitions. Parameter 286 defines the point in time when the heavy oil start
release is evaluated.
Repetition APS O 1 1-2
Sets the number of times the LMV3 will attempt to proceed past phase 24 when the air pressure switch
input X3-02.1 is not energized. After this number of tries, a lockout will occur.
Flame Sensitivity 0 0-1
Sets the flame signal sensitivity during phases 60 to 70 for ION (flame rod) and UV flame detectors.
0 = standard sensitivity
1 = high sensitivity
Flame Sensitivity
Switch Point
4 2-9
Sets the switching point on the fuel / air ratio curve for high flame sensitivity.
2 = no switching point (always high sensitivity)
3-9 = sets the point (P3-P9) to switch back to standard sensitivity
Repetition Actuator
Position
O 3 1-3
Sets the number of times the LMV3 will recycle if there is a issue moving the actuators to the commanded
positions. After this number of repetitions, a lockout will occur.
1 = no repetitions
2 = 1 repetition
3 = 2 repetitions
198
199
S/O
196
191 -
192
197
194
-
193 -
195 -
S
SCC Inc. Page 5 Section 3
