Siemens LMV3 series User Manual

LMV Series
Technical Instructions
LV3-1000
Gas Oil Gas Oil U/S/O Default Range Description
Parameter #
Fuel 0
Fuel 1
LEGEND - Password Access: U = User, S = Service, O = OEM, U/S = View - User, Write - Service, S/O = View - Service, Write - OEM
Shaded Parameters = Frequently Used. ** Parameters = Must Set. Fuel 1 parameters for LMV36 only.
Parameter Name
Speed Delta
Displays the real time difference between the target speed (in %) and the actual speed (in %). Used to
observe the accuracy of the VSD speed control through the operating range.
Actual Speed RPM Displays the real time speed of the VSD. Displayed in RPM.
Actual Speed % U Displays the real time speed of the VSD. Displayed as a percentage of the standardized speed.
Active Load
Source
S
This setting displays the active load source. There are five ways of sending a load command to the LMV3. If
multiple commands are received at the same time, the LMV3 uses the following priorities to determine
which command to follow:
1 = setting the fuel-air ratio curve (via parameter 400)
2 = manual mode (enabled during operation or via parameter 121)
3 = Modbus command on terminal X92
4 = 4-20 mA signal on terminal X64
5 = 3-position signal on terminals X5-03.2 and X5-03.3 (LMV37 only)
Current Fuel U Parameter only exists on an LMV36: Displays the current fuel selected (0 or 1).
Input Status Displays the status of the inputs (index 00) and outputs (index 01) with a bit-coded total.
Input Count Contact feedback network counter register.
Output Status Displays the required state of the output relays with a bit-coded total.
Incoming Voltage
Displays the real time mains voltage. For 120 VAC power, multiply the displayed value by 0.843. For 230
VAC power, multiple the displayed value by 1.683. Measured at terminal X3-04 pin 4 and pin 5.
Flame Signal
Displays the raw flame signal from 0-100% for any flame scanner type. A flame failure occurs when the
flame signal drops below 24% for the time period specified by parameter 186 (fuel 0) or 187 (fuel 1). This
signal refers to input terminal X10-06 (UV scanners) or input terminal X10-05.2 (flame rods).
Actual Fuel Flow Displays the real time fuel flow.
Actual Phase Displays the real time phase of the LMV3.
Actual Fault Displays the real time fault code.
Actual Diagnostic Displays the real time fault diagnostic.
Fault Number
Displays the total number of fault flags. This value can be reset by pressing the left or right arrow to change
the value to 00000000 and then pressing Enter.
S
935
936
942
945
947
948
950
933
S
Reset only
951
954
960
961
981
982
992
Read only
S
U
