25/213

Building Technologies Basic documentation LMV37.4... CC1P7546en

HVAC Products 4 Technical Data 01.12.2009

4.3 Environmental conditions

Storage DIN EN 60721-3-1

Climatic conditions Class 1K3

Mechanical conditions Class 1M2

Temperature range -20...+60 °C

Humidity <95 % r.h.

Transport DIN EN 60721-3-2

Climatic conditions Class 2K2

Mechanical conditions Class 2M2

Temperature range -30...+60 °C

Humidity <95 % r.h.

Operation DIN EN 60721-3-3

Climatic conditions Class 3K3

Mechanical conditions Class 3M3

Temperature range -20...+60 °C

Humidity <95 % r.h.

Caution!

Condensation, formation of ice and ingress of water are not permitted!
