30/213

Building Technologies Basic documentation LMV37.4... CC1P7546en

HVAC Products 6 Basic unit 01.12.2009

6 Basic unit

6.1 Description of inputs and outputs

This chapter covers the key features of the basic unit’s inputs and outputs. For exact

use of the inputs and the activation of outputs, refer to Sequence diagrams.

LMV...

Bild 271e /04 09

Protective earth PE

Ionization probe (ION)

QRB.../ QRC... signal voltage

QRB... / QRC... GND

X10-05

Figure 5: Flame signal input X10-05

LMV...

Bild 272/0409

QRA...

X10-06

Figure 6: Flame signal input X10-06

Connection choices:

• Ionization probe

• QRA2... / QRA10...

• QRA4.U

• QRB...

• QRC…

Flame signal input and

flame detector X10–05

and X10–06
