Page 56 MultiRanger 100/200 – INSTRUCTION MANUAL 7ML19981FB05
mmmmm
Alarms
With P112 and P113, you can set a high alarm (P112 > P113) or a low alarm (P112 < P113).
This shows a high alarm:
The temperature source can be the temperature sensor built into the transducer or an
external TS-3, as set by P660.
Loss of Echo (LOE)
Parameter Index Value Description
P111 5 5 Alarm on temperature
P112 5 45 ON setpoint at 45 °C
P113 5 43 OFF setpoint at 43 °C
P110 5 1 Take the temperature reading from
Transducer One
Parameter Index Value Description
P110 5 1 Alarm on LOE for Transducer One
P111 5 6 Alarm on LOE
P070 G 0.5 Trip alarm when 0.5 minutes (30 seconds)
pass without detecting a valid echo.

Siemens MAG 6000 Specifications

General

Type	Electromagnetic Flow Meter
Nominal Diameter	DN 15 to DN 3000
Lining Material	PTFE, Hard Rubber, Polyurethane
Electrode Material	Stainless Steel, Hastelloy, Tantalum, Platinum
Flow Rate Range	0 to 12 m/s
Protection Class	IP67, IP68
Communication	HART, PROFIBUS PA, PROFIBUS DP, FOUNDATION Fieldbus
Output Signals	4 to 20 mA, Pulse/Frequency
Power Supply	24 V DC
Process Temperature Range	-40°C to +180°C (depending on lining material)
Ambient Temperature Range	-40°C to +60°C
